The obstacle avoidance radar is a highly integrated wide-beam millimeter-wave radar, mainly used to detect whether there are obstacles within a certain area and to give two types of alarm signals indicating different levels of danger based on the distance of the detection. At the same time, the millimeter-wave radar has strong environmental adaptability and is not affected by light.

Taking into account the effects of sunlight, smog and rain/snow, it can provide 24-hour and all-weather safety protection.

The obstacle avoidance radar employs MIMO and Pulse Doppler technologies to detect moving and stationary targets within the scene. The antenna uses sparse array technology to enhance the accuracy of measurement angles. Any target that is active within the area covered by the radar beam can be effectively detected.

And it can accurately measure its speed, direction and distance, etc. The obstacle avoidance radar provides two relay signal output functions. Users can control the range of relay alarms by setting the detection area. At the same time, this radar is small in size, light in weight, and easy to install. These features all…

This enables the radar to have wide practical value.

The main features of XW-BZ-RD801 obstacle avoidance radar:

By adopting 80GHz MIMO + DBF technology, the performance is even more superior.

It can accurately measure the distance and speed of multiple targets, and ensure stable obstacle avoidance.

Employing sparse array technology to enhance the angular resolution;

It is easy to install, easy to debug and has simple maintenance.

It has strong adaptability to the environment and its detection performance is not affected by external factors such as light, dust, rain and snow.

It is widely applicable to scenarios such as obstacle avoidance for gantry cranes, stacker cranes, crane trolleys, and ship unloading cranes.

避障雷达是一款高集成度的宽波束毫米波雷达，主要用于检测一定区域内是否存在障碍物，并根据检测距离的远近给出两种危险程度的报警信号。同时，毫米波雷达具有很强的环境适应性，不受光

照、雾霾和雨雪的影响，可提供全天时、全天候的安全保障。

避障雷达采用 MIMO 和Pulse Doppler 技术对场景内的运动、静止目标进行探测。天线采用稀疏阵技术提高了测量角精度。凡是在雷达波束覆盖的区域内活动的目标，都能够被有效的检测出来，而

且可以准确地测量其速度，方位和距离等信息。避障雷达提供了2 个继电器信号输出功能，用户可通过设置检测区域，来控制继电器报警的范围。同时，该雷达体积小、重量轻、便于安装，这些特点都

使得该雷达具有广泛的实用价值。

XW-BZ-RD801 避障雷达主要特点:

l 采用80GHz MIMO + DBF技术，性能更优越；

l 可对多目标进行精确测距测速，稳定避障；

l 采用稀疏阵技术提高角度分辨率；

l 安装方便，易调试，维护简单；

l 环境适应性强，检测性能不受光照、灰尘、雨雪等外界环境干扰。

l 广泛适用于行台车避障，堆取料机避障，天车航车避障，门机吊车卸船机避障等场景。
